Technical Data:

• Temperature Range: -70 to 180C
• Humidity Range: 10 to 98%RH
• Accuracy: +/-1C ; +/-3%RH
• Uniformity: +/-1C ; +/-3%RH
• Resolution: 0.01C; 0.1%RH
• Heating Rate: 3C (Standard),  (option with 5C/min or more)
• Cooling Rate: 2C (Standard),  (option with 5C/min or more)
• Power Supply: 3phase 400Vac 50/60Hz
• Meet EN-61010-1 Safety of Machine, CNS, JIS, ISO and ASTM standard
• With CE Certificate

Key Features:

• Controller: TEMI2700 LCD touch screen digital display controller, programmable

• Mode: Fix or Program mode

• PLC microprocessor, PID control of temperature and humidity

• Both Temperature and humidity are programmable (can have 100pattern, each pattern has 120 segment, can repeat pattern, segment or part of segment)

• Sensors: PT100 and  digital humidity probe

• With RS232 output to computer

• English window Software (for PC editing, control, data storage)

• All 304 Stainless Steel (both interior and exterior)

• Single door or doube-wing doors

• Reinforced floor for heavy loading

• With Viewing Window

• With thermostats (prevent overheat)

• Entry cable ports (50 or 80 or 160mm diameter)

• With data storage on SD flash card

• Protection (MCCB circuit protection, phase protection, overheat, overcurrent etc)

• Auto-water refill valve and filter

• Extra large water storage tank

• Air cool or water cool

• Standard: meet EN60204 safety of machine, CNS, JIS, ISO and ASTM standard

Note1 : With -H temperature up to 180C
Note2 : Our standard Humidity Range is 20 to 98%RH. (Option: 10%RH)
